Marshall Slot Drainage

Marshall Slot Drainage 3,8/5 4567 reviews
  • Weep Holes in Brick Walls Provide Rain Screen Drainage, Definition & explanation of brick wall weep holes or weep openings. Damaged Brick Veneer Walls due to omission of or clogged Weep OpeningsWeep holes in brick walls: this article explains the purpose of drainage openings & rain screens in solid brick walls and in some brick veneer walls: brick wall weep holes and recommends their use in.
  • Aco building drainage Stainless steel corrosion resistant drainage systems for applications across the internal and external built environments. Select Business Type.
Marshall slot drainage pipe

Marshalls' Drexus Slot Drain is the ideal solution for projects requiring an effective drainage solution that doesn't compromise on the aesthetics of the overall landscape.

PipePRINT FRIENDLY PDF

• Durable construction for residential and light commercial applications
• Trench boxes have anchoring brackets for additional support
• Sections easily bolt together for continuous runs
• Steel grates held in place with stainless steel clips and screws
• All drains coated inside and out with red corrosion-resistant paint
• Tees, Els, and Jays available for corner applications
• Lower cost alternative to non-metallic drains

ModelSizeDescription
6TDSG6”Steel Bottom w/ Steel Grate
6TDB6″Steel Bottom Box Only
6SG6″Steel Grate Only
6EPS6”End Plate – Steel – Solid
6EPSWH6″Steel End Plate w/ 4-1/4″ Hole
8TDB8″Open Bottom Box Only
8SG8″Steel Grate Only
8EPS8″Steel End Plate – Solid
8EPSWH8″Steel End Plate w/ 4-1/4″ Hole
12TDSG12″Open Bottom w/ Steel Grate
12TDB12″Open Bottom Box Only
12SG12″Steel Grate Only
12EPS12”End Plate – Steel – Solid
12EPSWH12”Steel End Plate w/ 4-1/4″ Hole

Marshall Slot Drainage Pipe

Product Widths Trench Sizes
6”8”12”
Top (W)6-1/2”8-1/4”12-1/4”
Grate (WG)5-7/8”7-7/8”11-7/8”
Box (WI)4-1/2”6-1/4”10-1/4”

Standard Length:
• 6″ Wide-1′, 4′, 5′, and 6′
• 8″ Wide-4′, 5′, and 6′
• 12″ Wide-4′, 5′ and 6′

Marshalls Slot Drain

Slot

Skid Quantities:
• 6″-4′ and 5′-49 pieces
• 6″-6′-35 pieces
• 8″-4′-25 pieces
• 12″-4′-15 pieces
